Why Does My Ps2 Not Read Blue Discs
Chosen Solution
Was this answer helpful?
Score 3
I have heard of this solution before and I tried it but there's a chance the lens is "too old" and it might need to be changed.
If ifixit.com can post the guide to that, it would help?
ps. When my problem comes up, before the "Disc Read Error" message shows up, I usually hear the disc spinning followed by some dull click-click-click sound a few times repeating. Is that similar to your situation?
Was this answer helpful?
Score 1
Comments:
Yes, before getting any error there is a clicking coming from the DVD drive. The disc is definitely spinning while this is happening too. Hopefully there is a fix that doesn't require a replacement lens...
You could also try to adjust the potentiometers that set the current strength flowing thru the lens coils. If you make the resistance of the potentiometer 5-10% lower than what it currently is it will probably be more than enough to read your DVD discs. You have to take apart the PS2 then unscrew the 4 screws on top of the disc drive (fat models only). Take heed of ejecting the tray before unscrewing the 4 top screws off of the drive. Then take the rails out (the laser head rests on them) and turn the laser head over. You will see 2 small pots in there. Maybe they have a cd / dvd text written near them or maybe not - the thing is one of them adjusts the current for reading cd discs the other is for dvd discs. If you want to make sure all is good then measure their current values with a multimeter and take note of it. Then subtract 5% first from both of them, adjust, measure and put everything all together. I think the screw needs to be turned anti-clockwise to lower the value. It should work; but if it does not then repeat and subtract an other 5%. You should not lower the value by more than 15-20% as that would almost immediately kill the laser very .
Was this answer helpful?
Score 1
I had this problem with Playstation 2 Slim. Your advice to clean the optical disk drive lens worked great. One note: on the slim the cleaning is easy as you do not have to take it apart. On the PS2 Slim they switched from a DVD tray drive to a flip top DVD drive. So all I had to do was press the button to open it, reach in with an alcohol moistened Q-tip (not too wet) and give it a few wipes, let it dry and it started reading DVDs again.
Thanks much!
Was this answer helpful?
Score 0
Reading these comments nobody really has a clue how to fix the problem, you can pick up ps2 consoles so cheap these days just buy another keep the old one for spares or sell on ebay for £20+.
Was this answer helpful?
Score 0
Source: https://www.ifixit.com/Answers/View/28616/PS2+Reads+CDs+but+not+DVDs
I followed this guide and it half-fixed my problem - the console now reads DVD discs to an extent, but it still has issues. A DVD video I tried to play was really stuttery and a game I tried in it came up with the PlayStation 2 logo but then froze on a black screen. Sometimes the console will change to a red version of the main menu screen and ask me to insert a PlayStation or PlayStation 2 disc.
Thanks for the guide though, at least it has helped me make some progress :)
